▶ Additional information
Diameter (inches) : 60mm-300mm
Structure: FEP (Polyperfluoroethylene propylene).
Packing : 4/10/20meters Length in one carton box
▶ Basic Information
▶ Contact Information
Email: sales04@ducting.cn
Whatsapp: +86 13918360649
Electronic·Semiconductor Hose FEP
Description
QJ03126 hose
Application: Suitable for inhaling and transporting various chemicals, highly corrosive and highly oxidizing liquids and gases. Widely used in semiconductor, wafer manufacturing and testing, chips, photovoltaics, precision electronic equipment, chemical pharmaceutical industries, transporting various highly clean gases, liquids, etc.
Properties: Double corrugated structure, soft and easy to bend, with excellent corrosion resistance, insoluble in chemical solvents, not corroded by aqua regia, strong acids, strong alkalis and other strong corrosive substances, resistant to strong organic solvents, strong chemical substances, does not penetrate, non-toxic, no dust or impurities, no foreign substances leakage, prevents product and environmental pollution, will not cause contact pollution to the product, can withstand high temperatures and mechanical stress.
Structure: FEP (Polyperfluoroethylene propylene).
Temperature range: Approximately -85℃ to +200℃.
Both ends can be customized for flat end connectors.
| Inner Diameter | Outer Diameter | Bending radius | Work stress | Weight | Production length |
| (mm) | (mm) | (mm) | (bar) | (kg/m) | (m) |
| 6 | 11 | 25 | 8 | 0.1 | 20 |
| 8 | 13 | 25 | 8 | 0.12 | 20 |
| 10 | 16 | 50 | 8 | 0.16 | 20 |
| 13 | 18 | 65 | 6 | 0.29 | 20 |
| 16 | 21 | 75 | 6 | 0.35 | 20 |
| 19 | 24 | 85 | 6 | 0.5 | 20 |
| 22 | 27 | 95 | 6 | 0.6 | 20 |
| 25 | 32 | 100 | 5 | 0.65 | 20 |
| 32 | 40 | 120 | 4 | 0.85 | 20 |
| 38 | 45 | 135 | 3 | 1.1 | 20 |
| 50 | 63 | 165 | 2 | 1.9 | 10 |
| 63 | 78 | 230 | 1.5 | 2.39 | 4 |
| 76 | 87 | 260 | 1.3 | 2.98 | 4 |
| 100 | 118 | 300 | 1 | 3.95 | 4 |
| 125 | 144 | 450 | 1 | 4.95 | 4 |
| 150 | 176 | 520 | 1 | 6.75 | 4 |
