Polyester R1.0 Insulated Flexible Duct

Description

SGS Polyester Insulated Duct Black PVC Outer Layer

The 6 inch insulated flexible duct (6 x 25 ft) is an R6-rated air duct engineered for HVAC systems in manufactured housing and

mobile home environments. This duct features a high-efficiency nonwoven polyester insulation layer, a double-layer aluminum

foil inner core, and a black PVC outer jacket, offering both mechanical strength and energy-saving thermal performance.

Its oversized core allows for a snug yet easy fit over standard collars and register boxes—reducing leakage and installation hassle.

Lightweight and pre-compressed, this 6 x 25 flexible duct R6 model is ideal for confined or retrofit HVAC layouts requiring both airflow flexibility and insulation reliability.

Product Features: 6 x6M Flexible Duct R1.0

• Size: 6 inch diameter ×6M length (compressed packaging for easy handling), max size can be 32 ft
• Insulation: Thick polyester fiber insulation (25–30 mm) with stable R6 performance
• Inner Core: Constructed with double-layer aluminum foil for reinforced air seal
• Outer Jacket: Black PVC-coated aluminum foil, offering abrasion and moisture resistance
• Wire Helix: Carbon steel spring wire for shape retention and easy bending during installation
• Temperature Range: -30°C to +150°C
• Maximum Air Velocity: 30 m/s
• Working Pressure: Up to 3000 Pa
• Compression Ratio: 10:1
• Compliance: SGS, meets R6 energy efficiency standards

• Technical Specifications

• Item	Specification
  Outer Sleeve	Black PVC Outlet Jacket
  Insulation Material	Polyester, Thickness: 25mm / 30mm
  Polyester Density	Density: 100–750 g/m³
  Inner Duct	Double-layer Aluminum
  Fiberglass(option)	Thickness: 25mm / 30mm 12kg/m3,16kg/m3,20kg/m3,24kg/m3,32kg/m3
  Thermal Resistance	R4.2, R6, R8 (optional insulation thickness)
  Maximum Air Velocity	30 m/s
  Working Pressure	Up to 3000 Pa
  Available Diameter	10″ (254mm), other sizes from 2″–25″
  Temperature Range	-30°C to +150°C
  Steel Wire Diameter	0.6–2.5 mm (carbon steel spiral)
  Standard Length	10 m (customizable upon request)
  Ease of Cutting	No special tools required; easy to connect
  Fire & Pressure Testing	Passed fire resistance and pressure tests
  Flexibility	Can be bent in any direction (small bending radius)
  Space Saving	Compression ratio of 10:1
  Installation	Easy installation; long service life

Why Choose Polyester Insulation?

As an R1.0 polyester insulated duct, this product delivers a clean, safe alternative to fiberglass while maintaining stable thermal performance. Polyester insulation is:

• Non-toxic and low-irritation – Ideal for residential or low-contact installation environments
• Structurally resilient – Maintains its shape after compression, preserving R-value over time
• Eco-conscious – More recyclable and cleaner to handle compared to glass-based insulations

The R6 rating makes this duct suitable for most HVAC applications, particularly when ducts pass through unconditioned zones or attics where heat loss can be significant.

Conclusion: A Professional Choice in Insulated Flexible Duct Work

When selecting ducting for temperature-sensitive or space-limited environments, the 6 inch insulated flexible duct with R1.0 polyester insulation and PVC jacket is a reliable, durable, and code-compliant solution. Designed for energy efficiency and installation ease, it meets the demands of modern HVAC system upgrades or new builds.

📩 Contact us for availability, pricing, or customization of your next insulated flexible ducting 150mm project. We offer OEM services and fast production for global clients.
